Special Projects 3D Laser Scanning & Modeling

Due to our extensive experience with 3D Laser Scanning and as-built documentation, Reality IMT handles unconventional projects with a reverse engineering approach. We start out by understanding the problem statement, what is it that you are trying to accomplish and what would be the deliverable. We can also make recommendations on what tools are best fit for acquiring the data.

We utilize best management practices for data acquisition, processing and delivery to help you achieve the inspection results you are seeking. Our special projects include:

  • Crusher Plants
  • Conveyor Belts & Assembly Lines
  • Dredgers
  • Vessels
  • Aircrafts
  • Heavy Trucks & Fueling Stations
  • Oil and Gas Loading Docks

Sand Dredger Volumetric Calculations

3D Laser Scanning-Dredger

The dredger was scanned using a stationary 3D Laser Scanner and a precise 3D CAD model was developed. Volumetric calculations were then done in sections to ensure accuracy. Pipe and structural members volume is deducted from the total volume to pin point the exact capacity of the dredger. This project helped the operations and planning team better plan their dredging activities and project schedule, resulting in tremendous cost savings overt the life time of the project.
